- Choice of Flat (FRFR) or Speaker Modeling modes
- Choice of 12 onboard Speaker Models (+ IR loading)
- Plays your stereo presets in stereo not mono
- 500-watt stereo amplifier (2 x 250 watts) delivers up to 131dB SPL
- Lightweight 12″ neodymium coaxial speakers with high-frequency compression drivers and robust 2″ voice coils
- 70Hz-20kHz neutral frequency response in Flat mode
- 128 Presets configurable for Flat, Speaker Modeling, or IR mode
- MIDI In/Out, AES/EBU I/O, L6 LINK, USB audio interface
FLAT RESPONSE MODE
CUSTOM GUITAR SPEAKERS
SPEAKER MODELING MODE & IR LOADING
STEREO & DUAL MONO
PERFORMANCE READY
DIGITAL CONNECTIVITY
THE ULTIMATE CAB FOR HELIX
Tech Specs
- Configuration:2 x 12″
- Powered:Yes
- Speakers:12″ Eminence Coaxial Neodymium Speaker, 1″ Celestion CDX Compression Driver
- Total Power:500W
- Mono/Stereo:Stereo, Dual Mono
- Cabinet Type:Straight, Tilt back
- Open/Closed Back:Closed
- Inputs:2 x XLR-1/4″ combo, 1 x XLR (AES in/L6 link)
- Outputs:2 x XLR, 1 x XLR (AES out/L6 link)
- Other I/O:MIDI In, Out/Thru, 1 x USB Type B
- Maximum Peak SPL:131dB SPL
- Frequency Range:70Hz-20kHz
- Construction Material:Poplar Enclosure
- Height:21.1″
- Width:28″
- Depth:12″
- Weight:47.6 lbs.
- Manufacturer Part Number:99-010-7205
