Name: NEW DigiTech FreqOut Natural Feedback Creator Guitar Effects FX Pedal Stompbox
SKU: 22941
Availability: OutOfStock

The DigiTech FreqOut Natural Feedback Creator allows you to get sweet, natural feedback at any volume, with or without distortion. The FreqOut is perfect for situations where volume must be controlled like in the studio, with in ear monitors, or low-volume performance and practice. However, the FreqOut can also be used at gig volume to focus out-of-control feedback on a preferred harmonic at any stage position.

More Details

The FreqOut has adjustable feedback Onset (delay before feedback begins), Gain (feedback level to balance with your dry signal), Dry On/Off, latching or momentary operation, true bypass, and a rugged road-tough steel chassis.

The FreqOut uses a 9VDC power supply to easily integrate into your existing pedalboard.

Audio Demos

Documentation

Safety and Quick Start Guide-English [595 KB]
How It Works [603 KB]
Owner’s Manual-English [1.72 MB]

Features

Natural Feedback at any level with or without distortion
Onset Delay and Level balance controls
7 Harmonic Feedback types
Dry Defeat
Momentary/Latching modes
True Bypass

Specifications

Input	1/4″ Unbalanced (Tip-Sleeve)
Max Input Level	+5 dBu
Input Impedance	1 MΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off)
Output	1/4″ Unbalanced (Tip-Sleeve)
Max Output Level	+10 dBu
Output Impedance	1 kΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off)
Controls	Feedback, Momentary On/Off, Dry On/Off, Gain, Onset, Type, Effect On/Off
Signal to Noise Ratio	> -106dB (A weighted); ref = max level, 22 kHz bandwidth
THD	0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
Power Consumption	2.1 Watts (235 mA typical @ 9 VDC)
Power Requirements	9 VDC External Adapter (sold separately)
Power Supply	PS0913DC-04 (US, JA, EU, AU, UK)
Power Adapter Output	9 VDC 1.3 A
Weight	0.8 lbs. (0.363 kgs.)
Dimensions	4.75” (L) x 2.875” (W) x 1.75” (H)
